D-ILA Projector Series

D-ILA

Blissful moment for you

2023
New Features

Frame Adapt HDR Generation 2*1

  • NZ9
  • NZ8
  • NZ7
  • NP5

The Frame Adapt HDR technology, which uses a proprietary algorithm to instantaneously analyze the maximum brightness of HDR10 content per frame and adjust the dynamic range in real time to the optimum range for video projection on projectors, has evolved into the second generation. As the culmination of the HDR image processing technology that has been cultivated up to now, the tone mapping algorithm has been completely reexamined in accordance with the scene and frame to achieve HDR images with higher definition creating an immersive three-dimensional feeling  by suppressing the whiteness especially in the high brightness area. In addition, the proprietary algorithm for tone curve selection has been improved to reproduce HDR images that are brighter, more colorful, and have a wider dynamic range.

Light Source Control by Gauge*1

  • NZ9
  • NZ8
  • NZ7

The laser light source can be finely adjusted according to the environment and preference using the Light Source Control by Gauge featured on the latest BLU-Escent models. The function has been updated from the previous 3 steps to enable fine 0 -100 steps adjustment of luminance, based on the brightness of the screen and flexible setting according to the usage environment.

USB Back-up*1

  • NZ9
  • NZ8
  • NZ7
  • NP5

The USB Back-up  function can save and write settings on the main unit menu to a third-party USB flash drive  all at once. It is important to save adjustments made by an installer or specialist, or to undo unintended adjustments made by children or family members.

*1 : The feature will be available through a firmware update scheduled for November 2023.

Main Features

PRODUCTS

8K/e-shift X

DLA-NZ9

DLA-NZ9
  • Promo retail $22,999.95 ($3,000 Savings)
  • 8K60p/4K120p input with 8K/e-shiftX
  • 0.69-in 4K D-ILA
  • 100mm High Resolution All Glass Lens
  • BLU-Escent(Laser Light source) and Ultra-High Contrast Optics realizes 3,000 lm Light Output
  • 100,000:1 Native Contrast ∞:1 Dynamic Contrast
  • NEWFrame Adapt HDR Generation 2 *1
  • HDR(HDR10+/HLG)
  • Wide Color Gamut (DCI cover)
8K/e-shift X

DLA-NZ8

DLA-NZ8
  • Promo retail $13,999.95 ($2,000 Savings)
  • 8K60p/4K120p input with 8K/e-shiftX
  • 0.69-in 4K D-ILA
  • 65mm High Resolution All Glass Lens
  • BLU-Escent(Laser Light source) and Ultra-High Contrast Optics realizes 2,500 lm Light Output
  • 80,000:1 Native Contrast ∞:1 Dynamic Contrast
  • NEWFrame Adapt HDR Generation 2 *1
  • HDR(HDR10+/HLG)
  • Wide Color Gamut (DCI cover)
8K/e-shift

DLA-NZ7

DLA-NZ7
  • $8,999.95
  • 8K60p/4K120p input with 8K/e-shift
  • 0.69-in 4K D-ILA
  • 65mm High Resolution All Glass Lens
  • BLU-Escent(Laser Light source) realizes 2,200 lm Light Output
  • 40,000:1 Native Contrast ∞:1 Dynamic Contrast
  • NEWFrame Adapt HDR Generation 2 *1
  • HDR(HDR10+/HLG)
4K

DLA-NP5

DLA-NP5
  • Promo retail $4,999.95 ($1,000 Savings)
  • 4K120p input
  • 0.69-in 4K D-ILA
  • 65mm High Resolution All Glass Lens
  • 1,900lm Light Output
  • 40,000:1 Native Contrast 400,000:1 Dynamic Contrast
  • NEWFrame Adapt HDR Generation 2 *1
  • HDR(HDR10+/HLG)

*1: The feature will be available through a firmware update scheduled for November 2023.

SPEC

Specifications

Specifications

DLA-NZ9 DLA-NZ8 DLA-NZ7 DLA-NP5
Device 0.69-inch Native 4K D-ILA Device (4096x2160) x3
e-shift 8K/e-shiftX 8K/e-shift -
Display Resolution 8192 x 4320 4096 x 2160
Lens Type x2 Motorised Zoom & Focus, All-glass Lens
Diameter 100 mm 65 mm
Lens Shift Vertical/Horizontal (motorised) *In 16:9 aspect ratio mode ±100% / ±43% ±80% / ±34%
Projection Display Size 60 inch - 300 inch (diagonal) 60 inch - 200 inch (diagonal)
Light Source Laser Diode NSH 265 W
Brightness 3,000 lm 2,500 lm 2,200 lm 1,900 lm
Contrast Ratio Dynamic ∞:1 400,000:1
Native 100,000:1 80,000:1 40,000:1 40,000:1
DCI-P3 Color Gamut - -
Input Terminal HDMI 2 (48Gbps, HDCP2.3, CEC does not support)
TRIGGER 1 (Mini Jack, DC12V/100mA)
Output Terminals 3D SYNCHRO 1 (Mini-Din 3pin)
RS-232C 1 (Dsub 9pin)
Control Terminals LAN 1 (RJ-45)
Service Terminal SERVICE 1 (USB Type A) (for firmware update)
Video Input Signal Format Digital 480p, 576p, 720p 60/50, 1080i 60/50,
1080p 120/100/60/50/30/25/24,
2048x1080 60/50/30/25/24,
3840x2160 120/100/60/50/30/25/24,
4096x2160 120/100/60/50/30/25/24,
7680x4320 60/50/48/30/25/24
480p, 576p, 720p 60/50, 1080i 60/50,
1080p 120/100/60/50/30/25/24,
2048x1080 60/50/30/25/24,
3840x2160 120/100/60/50/30/25/24,
4096x2160 120/100/60/50/30/25/24
PC Input Signal Format Digital (HDMI) VGA/SVGA/XGA/WXGA/WXGA+
SXGA/WSXGA+/UXGA/WUXGA/WQHD(60)/WQHD(120)
3D Format Frame Packing 720p 60/50, 1080p 24
Side-by-Side (half) 720p 60/50, 1080p 60/50/24, 1080i 60/50
Top & Bottom 720p 60/50, 1080p 24
Power Consumption Projector in use 440 W 440 W 420 W 420 W
Standby Eco-mode: 0.3W Eco-mode: 0.3W Eco-mode: 0.3W Eco-mode: 0.3W
Networked standby 1.5W(LAN) 1.5W(LAN) 1.5W(LAN) 1.5W(LAN)
Fan Noise 24dB (When the Low Mode) 24dB (When the Low Mode) 24dB (When the Low Mode) 24dB (When the Low Mode)
Power Requirement AC100-240 V, 50/60 Hz
Dimension (W x H x D, including feet) 500 x 234 x 528 mm 500 x 234 x 505 mm 500 x 234 x 495 mm
19-11/16 x 9-7/32 x 20-13/16 inch 19-11/16 x 9-7/32 x 19-29/32 inch 19-11/16 x 9-7/32 x 19-1/2 inch
Weight (net) 25.3 kg 23.1 kg 22.5 kg 19.6 kg
55.7 lbs 50.8 lbs 49.5 lbs 43.12 lbs

DLA-NZ9 Appearance

DLA-NZ9 External Dimensions (Unit : inch/mm)


DLA-NZ8/DLA-NZ7 Appearance

DLA-NZ8/DLA-NZ7 External Dimensions (Unit : inch/mm)


Appearance

DLA-NP5 External Dimensions (Unit : inch/mm)


Terminals on the rear

Main Features

Main Features

DLA-NZ9 DLA-NZ8 DLA-NZ7 DLA-NP5
8K/e-shiftX (4-direction shift) - -
8K/e-shift (2-direction shift) - - -
8K60p Input -
4K120p input
Lens Diameter 100 mm 65 mm 65 mm 65 mm
Light Source Blu-Escent Laser Diode Blu-Escent Laser Diode Blu-Escent Laser Diode NSH 265 W
Light Source Control 0-100 steps *1 0-100 steps *1 0-100 steps *1 Low / Hight
Brightness 3,000 lm 2,500 lm 2,200 lm 1,900 lm
0.69-inch 4K D-ILA Device
Ultra-High Contrast Optics - -
Contrast Ratio Dynamic ∞:1 400,000:1
Native 100,000:1 80,000:1 40,000:1 40,000:1
Cinema Filter (DCI-P3) - -
HDR HDR10+
HLG
Mastering Info Display ● (Max CLL/Max FALL) ● (Max CLL/Max FALL) ● (Max CLL/Max FALL) ● (Max CLL/Max FALL)
Frame Adapt HDR Generation 2 *1
Theater Optimizer*2
Auto Tone Mapping
FILMMAKER MODE
3D Support
MPC (Multiple Pixel Control)
Clear Motion Drive
Motion Enhance
Low Latency Mode
Auto Calibration
Installation Mode ● (10 memories) ● (10 memories) ● (10 memories) ● (10 memories)
isfccc Certification
Screen Adjustment Mode ● (199 modes) ● (199 modes) ● (199199 modes) ● (199 modes)
USB Back-up *1

*1: The feature will be available through a firmware update scheduled for November 2023.

*2: Theater Optimizer can be activated only when the projector's picture mode is set to Frame Adapt HDR.

Projection Distance

DLA-NZ9 Projection Distance

Screen size aspect ratio: 16:9 Projection distance
Screen diagonal W (mm) H (mm) Wide (m) Tele (m)
60 1,328 747 1.75 3.61
70 1,550 872 2.06 4.23
80 1,771 996 2.37 4.84
90 1,992 1,121 2.67 5.46
100 2,214 1,245 2.98 6.07
110 2,435 1,370 3.28 6.69
120 2,657 1,494 3.59 7.30
130 2,878 1,619 3.90 7.92
140 3,099 1,743 4.20 8.53
150 3,321 1,868 4.51 9.15
160 3,542 1,992 4.81 9.76
170 3,763 2,117 5.12 10.38
180 3,985 2,241 5.43 10.99
190 4,206 2,366 5.73 11.61
200 4,428 2,491 6.04 12.22
210 4,649 2,615 6.34 12.84
220 4,870 2,740 6.65 13.45
230 5,092 2,864 6.96 14.07
240 5,313 2,989 7.26 14.68
250 5,535 3,113 7.57 15.30
260 5,756 3,238 7.87 15.91
270 5,977 3,362 8.18 16.53
280 6,199 3,487 8.48 17.14

Screen size aspect ratio: 2.35:1 (Cinematic) Projection distance
Screen diagonal W (mm) H (mm) Wide (m) Tele (m)
60 1,402 597 1.86 3.82
70 1,636 696 2.18 4.47
80 1,870 796 2.5 5.12
90 2,103 895 2.83 5.77
100 2,337 995 3.15 6.41
110 2,571 1,094 3.47 7.06
120 2,805 1,193 3.79 7.71
130 3,038 1,293 4.12 8.36
140 3,272 1,392 4.44 9.01
150 3,506 1,492 4.76 9.66
160 3,740 1,591 5.09 10.31
170 3,973 1,691 5.41 10.96
180 4,207 1,790 5.73 11.61
190 4,441 1,890 6.05 12.26
200 4,674 1,989 6.38 12.91
210 4,908 2,089 6.7 13.56
220 5,142 2,188 7.02 14.21
230 5,376 2,287 7.35 14.85
240 5,609 2,387 7.67 15.5
250 5,843 2,486 7.99 16.15
260 6,077 2,586 8.32 16.8
270 6,310 2,685 8.64 17.45

Screen size aspect ratio: 17:9 Projection distance
Screen diagonal W (mm) H (mm) Wide (m) Tele (m)
60 1,348 711 1.67 3.43
70 1,573 829 1.96 4.02
80 1,797 948 2.25 4.60
90 2,022 1,066 2.54 5.19
100 2,247 1,185 2.83 5.77
110 2,471 1,303 3.12 6.36
120 2,696 1,422 3.41 6.94
130 2,921 1,540 3.70 7.53
140 3,145 1,659 3.99 8.11
150 3,370 1,777 4.28 8.70
160 3,595 1,896 4.58 9.28
170 3,819 2,014 4.87 9.87
180 4,044 2,133 5.16 10.45
190 4,269 2,251 5.45 11.04
200 4,493 2,370 5.74 11.62
210 4,718 2,488 6.03 12.21
220 4,943 2,607 6.32 12.79
230 5,168 2,725 6.61 13.38
240 5,392 2,844 6.90 13.97
250 5,617 2,962 7.20 14.55
260 5,842 3,080 7.49 15.14
270 6,066 3,199 7.78 15.72
280 6,291 3,317 8.07 16.31
290 6,516 3,436 8.36 16.89
300 6,740 3,554 8.65 17.48

* Projection distances are design specifications, so there is ±5% variation.

DLA-NZ8/DLA-NZ7/DLA-NP5 Projection distance

Screen size aspect ratio: 16:9 Projection distance
Screen diagonal W (mm) H (mm) Wide (m) Tele (m)
60 1,328 747 1.88 3.85
70 1,550 872 2.20 4.50
80 1,771 996 2.52 5.15
90 1,992 1,121 2.84 5.80
100 2,214 1,245 3.16 6.45
110 2,435 1,370 3.49 7.10
120 2,657 1,494 3.81 7.75
130 2,878 1,619 4.13 8.40
140 3,099 1,743 4.45 9.05
150 3,321 1,868 4.77 9.70
160 3,542 1,992 5.09 10.35
170 3,763 2,117 5.41 11.00
180 3,985 2,241 5.73 11.65
190 4,206 2,366 6.05 12.30
200 4,428 2,491 6.38 12.95

Screen size aspect ratio: 2.35:1 (Cinematic) Projection distance
Screen diagonal W (mm) H (mm) Wide (m) Tele (m)
60 1,402 597 1.99 4.07
70 1,636 696 2.33 4.76
80 1,870 796 2.67 5.44
90 2,103 895 3.00 6.13
100 2,337 995 3.34 6.81
110 2,571 1,094 3.68 7.50
120 2,805 1,193 4.02 8.18
130 3,038 1,293 4.36 8.87
140 3,272 1,392 4.70 9.56
150 3,506 1,492 5.04 10.24
160 3,740 1,591 5.38 10.93
170 3,973 1,691 5.72 11.61
180 4,207 1,790 6.05 12.30

Screen size aspect ratio: 17:9 Projection distance
Screen diagonal W (mm) H (mm) Wide (m) Tele (m)
60 1,348 711 1.79 3.66
70 1,573 829 2.09 4.28
80 1,797 948 2.40 4.90
90 2,022 1,066 2.70 5.52
100 2,247 1,185 3.01 6.14
110 2,471 1,303 3.31 6.75
120 2,696 1,422 3.62 7.37
130 2,921 1,540 3.92 7.99
140 3,145 1,659 4.23 8.61
150 3,370 1,777 4.54 9.23
160 3,595 1,896 4.84 9.84
170 3,819 2,014 5.15 10.46
180 4,044 2,133 5.45 11.08
190 4,269 2,251 5.76 11.70
200 4,493 2,370 6.06 12.32

* Projection distances are design specifications, so there is ±5% variation.

Optional Accessories

HDMI Cable

VX-UH1150LC

HDMI Cable

VX-UH1150LC

  • Cable length 15m
  • 8K60p/4K120p/48Gbps Support
  • Ultra High Speed HDMI Cable certification

Replacement Lamp

PK-L2618U

Replacement Lamp

PK-L2618U

3D Option

PK-AG3

RF 3D Glasses

PK-AG3

  • Rechargeable Type
  • Lightweight-only 38g
  • Continuous operation approx.100H
  • Features 2D modes
  • Range of use: 10m (10 meter radius from the 3D Synchro Emitter)
  • Dimensions 170 x 40 x 165 mm (WxHxD)
PK-EM2

RF 3D Synchro Emitter

PK-EM2

  • Wireless (direct connection with the projector)
  • Lightweight-only 20g
  • Dimensions 48.9 x 14.5 x 65 mm (WxHxD)
Screen Adjustment Modes

Screen Adjustment Modes

Brand Screen Mode
- - 0*
- 1*
- 2*
- 3*
CARADA Classic Cinema White (Gs 1.0) 4
Brilliant White (Gs 1.4) 5
High Contrast Gray (Gs 0.8) 6
DA-LITE MATTE WHITE 7
HIGH CONTRAST MATTE WHITE 8
VIDEO SPECTRA 1.5 9
SILVER MATTE 10
HIGH POWER 11
DA-MAT 12
HIGH CONTRAST DA-MAT 13
CINEMA VISION 14
HIGH CONTRAST CINEMA VISION 15
PEARLESCENT 16
DUAL VISION 17
AUDIO VISION 18
HIGH CONTRAST AUDIO VISION 19
HIGH CONTRAST CINEMA PERL 20
3D VIRTUAL GREY 21
HD PROGRESSIVE 0.6 22
HD PROGRESSIVE 0.9 23
DIGIS Hight Contrast Gray (HCG) 141
Mat Whaite (MW) 142
DNP Supernova 08-85 104
Supernova 23-23 105
Dragonfly DFS-UW (Ultra White) 177
DRAPER FLEXABLE MATTE WHITE 24
FIBERGLASS MATTE WHITE 25
HIGH CONTRAST GREY 26
FLEXIBLE M 1300 27
HIGH DEF GREY 28
M 2500 29
Dreamscreen Ultraweave V6 175
Ultraweave V7 176
EASTONE E2S 30
ESECO 31
BF-3D Reference 96
E8K 186
ELITE CineWhite 89
PowerGain 90
Elite MaxWhite 91
MaxWhite FG 92
SilverGrey 93
ELUNE VISION Reference PureBright 4K 240 109
Reference Studio 4K 80 110
Reference Studio 4K 100 111
Reference Studio AudioWeave 4K 112
AURORA 4K 1.3 134
AURORA PERFORATED 4K 1.3 136
REFERENCE AUDIOWEAVE 4K+ 137
Focusview MP series Gain 1.4 181
MP series Gain 1.8 182
GOO SYSTEMS Reference White 2.0 166
High Contrast 2.0 167
Max Contrast 2.0 168
Ultra Max Theme Park 2.0 169
GRANDVIEW GRANDVIEW WHITE 37
WM5 153
GM5 154
WP5 155
WB5 156
WB7 157
BG7 158
GG3 159
WW3 160
RE3 161
AT5 162
AT6 163
AT7 164
AW6 165
UHD130 187
WW5 188
Harkness Screens Matt Plus mini Perf 170
HiWhite Gain 1.8 184
KAUBER Clear Vision (CLV) 143
Microperforated White (MPERFW) 144
White Flex (WFLEX) 145
Gray Flex (GFLEX) 146
Gray Pro (GPRO) 147
KIKUCHI WA 32
AM 33
AG 34
PG 35
MALIBU 36
GRACE MATT 100 101
WAC 102
SILVER 107
Dressty 4K 115
Chantilly White (CW) 173
SG 185
Lambda Studio SCIENCE UHD 1.0 WHITE 135
MicroliteScreen FRONT 1.2 122
FRONT 2.4 123
MULTIVISION Cinecitta 240 149
Woven sound fabric 150
High Contrast 151
Mattpreview 152
ORAY B3100100 38
B1100100 32/100 39
B1100100 25/100 40
BC100100 41
N3100100 MICROPERF 42
N3100100 SUPER BLANC 43
OS WG103 44
WG107G 45
WG201 46
WG206 47
WG207 48
WT101 49
WF201 50
WF202 51
WF203 95
WF301 106
WF302 108
SunnyWhite 52
BS101 53
BU102 54
PP201 55
BU202 94
BU201 103
HF102 148
AKIREI BU301 183
PROCOLOR MATTE WHITE C 56
MATTE WHITE P 57
SAYMOUR AV CENTER STAGE XD 129
CENTER STAGE UF 130
GLACIER WHITE 131
MATINEE BLACK 132
MATINEE SILVER 133
SAYMOUR SCREEN EXCELLENCE ENLIGHTOR BRIGHT 124
ENLIGHTOR 4K 125
AMBIENT VISIONAIRE 1.2 126
AMBIENT VISIONAIRE 1.3 127
AMBIENT VISIONAIRE 2.1 128
SCREEN RESEARCH ClearPix2 58
SI Pure Gray .85 59
Pure White 1.3 60
Gamma HD1.1 61
Maestro White 1.1 62
Lunar Maestro HD.85 63
Black Diamond II HD0.8 Black 64
Black Diamond II HD1.4 Black 65
SLATE .8 113
SLATE 1.2 114
Unity 172
360 Rear-Pro 189
BLACK DIAMOND XL 190
PURE GRAY .85 191
PURE GRAY AT .85 192
PURE WHITE AT 1.3 193
SHORT THROW 194
SLATE .8 195
SLATE 1.2 196
SLATE AT 1.2 197
SLATE XL 198
SOLAR GRAY XL 199
SOLAR WHITE XL 200
UNITY AT 201
Stewart SnowMatte 100 66
Ultramatte 130 67
Ultramatte 150 68
Ultramatte 200 69
StudioTek 100 70
StudioTek 130 G3 71
GrayMatte 70 72
FireHawk SST 73
FireHawk G3 74
FireHawk G4 120
GrayHawk RS 75
GrayHawk RS G4 116
SILVER 3D 97
SILVER 5D 98
Tela 80 117
Tiburon G2 118
Reflections 3D 121
Reflections Active 170 3D 99
HARMONY 138
ESTERO 100 139
NEVE 140
Phantom HALR 171
FireHawk G5 174
PHANTOM HALR+PLUS 202
STUDIOTEK130 G4 203
STUMPFL FLEX WHITE CI 100
Theaterhouse White Matte HD 76
Theater Matte HD 77
VNX Black Horizon 178
Black Horizon Bright TV 179
Black Horizon Acoustic 180
VUTEC MATTEWHITE 78
BRIGHT WHITE 79
VUFLEX PRO 80
PEARL BRIGHT 81
GREYDOVE 82
SOUND SCREEN-5 83
SOUND SCREEN-15 84
GREYDOVE SOUND SCREEN 85
TWIN VU 86
PREFORATED LEADER 87
SILVER STAR 88
  • * If none of the above applies,please select from 0 to 3
  • 0:OFF
  • 1:Correct to give a reddish tinge
  • 2:Correct to give a greenish tinge
  • 3:Correct to give a bluish tinge
  • * The Screen Adjustment Mode Table is that recommended by JVC.
  • * The exact results from any given the Screen Adjustment Mode Table will be affected to some degree by the installation environment, so this table should be used only as a guide.
  • * The mode used for any given screen is not a reflection of the quality of the screen.
  • * The mode 185 to 203 will be available through a firmware update scheduled for November 2022.
  • D-ILA is a registered trademark of JVCKENWOOD Corporation.
  • BLU-Escent is a registered trademark of JVCKENWOOD Corporation
  • HDR10+ logo is a trademark of HDR10+ Technologies, LLC.
  • FILMMAKER MODE logo is a trademark of UHD Alliance, Inc.
  • ISF is a registered trademark of Imaging Science Foundation, Inc.
  • HDMI, the HDMI logo and High-Definition Multimedia Interface are registered trademarks of HDMI Licensing LLC.
  • All other brand or product names may be trademarks and/or registered trademarks of their respective owners.
  • Please be aware that, because the D-ILA device is manufactured using highly advanced technologies, 0.01% or fewer of the pixels may be non-performing (always on or off).
  • DLA-NP5 is equipped with an ultra-high pressure mercury lamp, which may break, emitting a loud noise, when it is subjected to shock or after it has been used for some length of time.
  • Please note that, depending on how the projector is used, there can be considerable difference regarding how many hours the light source will operate before requiring replacement.
  • An additional payment is required for installation of the projector or a new light source, if necessary.
  • All pictures on this brochure are simulated.
  • Design and specifications are subject to change without notice.
  • Any rights not expressly granted herein are reserved.
